ZX Spectrum PSU for +2A, +2B, +3 NEW
£41.66 Ex. VAT
ZX Spectrum PSU for +2A, +2B, +3 is a modern, 50W strong, replacement power supply unit. It provides stable filtered 5VDC up to 4.0A, 12VDC up to 2.0A and -12VDC up to 0.5A. All by industrial grade AC/DC power supply. Carefully trimmed to offer best performance. The best and most affordable basic ZX Spectrum +2A PSU or ZX Spectrum +3 PSU replacement on the market. The one and only absolute industry standard using the Mean-Well’s RPT-60B as a base component,
Key features:
- ZX Spectrum +2A, +2B, +3 compatible
- Stabilized & filtered 5VDC up to 4A output (4.4A peak)
- Stabilized & filtered 12VDC up to 2A output (2.2A peak)
- Stabilized & filtered -12VDC up to 0.5A output (0.55A peak)
- Active & passive over voltage protection for main +5VDC line
- Over current protection for all output lines
- Fully isolated & fused on AC side
- Power On/Off switch
- Long output cable (1.8m) with round DIN 6-pin plug
- Detachable input AC cable for all versions
- Weight only 0.4 KG (4x less than original transformer based PSU)
- Runs COLD!
- Safety standards: UL60950-1, TUV EN60950-1, ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1
- UK Stock
Warning!
Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it’s not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values.
This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it’s not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system’s potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it’s >30 years old).
OUT OF STOCK
Email me when stock is available
You may also like…
&url=https://www.retropassion.co.uk/product/commodore-amiga-psu-for-1-x-a500-600-1200-1-x-cd32-a590-duo-plus-edition/&media=https://i0.wp.com/www.retropassion.co.uk/wp-content/uploads/2022/06/commodore-amiga-a500-a600-a1200-a590-cd32-psu-duo-plus-4.jpg?fit=800%2C800&ssl=1){kind=link}
Commodore Amiga PSU for 1 x A500/600/1200 1 x CD32/A590 (DUO PLUS EDITION)
Commodore Amiga PSU DUO EDITION PLUS for 1 x A500/600/1200 and 1 x CD32/A590 with the ability switch them on and off independently up to 4.0A per 5VDC channel with independent 5VDC adjustments per channel for regular and accelerated Commodore Amiga A500, A500+, A600 and A1200.
The new Amiga PSU DUO PLUS Edition is a modern, 65W strong replacement power supply unit for the Amiga computer systems.provides stable, filtered, adjustable 5VDC (up to 4.0A), +12VDC (up to 0.5A) and -12VDC (up to 0.15A) by industrial grade components. Now your Vampire, Blizzard, ACA, TF536, TF1230. TF1260 accelerator will get enough juice to work flawlessly with full MHz clocks. Factory trimmed for stock Amiga 500 reference load, may be adjusted to give exact 5VDC with 2-3x heavier loads.
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Key features:
- Stabilized, double protected +5VDC up to 4.0A rated output (per channel)
- Stabilized +12VDC up to 1.0A rated output (per channel)
- Stabilized -12VDC up to 0.15A rated output (per channel)
- Trim potentiometer for 5VDC fine adjustments (5-5.5V range) on every channel
- Double over current protection for all output lines
- Main AC power On/Off switch
- Two channel On/Off switches
- Each channel has a set of LED power good indicators (green 5VDC, yellow 12VDC, blue -12VDC).
- Eco friendly, green design: consumes ~20% less power compared to original PSU set
- Output cable length (1.5m) regular Amiga or CD32/A590 compatible.
- Detachable AC cable (allowing you to use your own desired cable length).
- Weight only 0.3 KG
- Safety standards: UL60950-1, TUV EN60950-1, ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1
- UK Stock
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
&url=https://www.retropassion.co.uk/product/commodore-amiga-psu-a500-600-1200-duo-plus/&media=https://i0.wp.com/www.retropassion.co.uk/wp-content/uploads/2022/06/commodore-amiga-a500-a600-a1200-a590-cd32-psu-duo-plus-4.jpg?fit=800%2C800&ssl=1){kind=link}
Commodore Amiga PSU for 2 x A500/600/1200 (DUO PLUS)
Commodore Amiga PSU DUO EDITION PLUS for 2 x A500/A600/A1200 with the ability switch them on and off independently up to 4.0A per 5VDC channel with independent 5VDC adjustments per channel forregular and accelerated Commodore Amiga A500, A500+, A600 and A1200.
The new Amiga PSU DUO Edition is a modern, 65W strong replacement power supply unit for Commodore Amiga computer systems.provides stable, filtered, adjustable 5VDC (up to 4.0A), +12VDC (up to 0.5A) and -12VDC (up to 0.15A) by industrial grade components. Now your Vampire, Blizzard, ACA, TF536, TF1230. TF1260 accelerator will get enough juice to work flawlessly with full MHz clocks. Factory trimmed for stock Amiga 500 reference load, may be adjusted to give exact 5VDC with 2-3x heavier loads.
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Key features:
- Stabilized, double protected +5VDC up to 4.0A rated output (per channel)
- Stabilized +12VDC up to 1.0A rated output (per channel)
- Stabilized -12VDC up to 0.15A rated output (per channel)
- Trim potentiometer for 5VDC fine adjustments (5-5.5V range) on every channel
- Double over current protection for all output lines
- Main AC power On/Off switch
- Two channel On/Off switches
- Each channel has a set of LED power good indicators (green 5VDC, yellow 12VDC, blue -12VDC).
- Eco friendly, green design: consumes ~20% less power compared to original PSU set
- Output cable length (1.5m) regular Amiga or CD32/A590 compatible.
- Detachable AC cable (allowing you to use your own desired cable length).
- Weight only 0.3 KG
- Safety standards: UL60950-1, TUV EN60950-1, ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1
- UK Stock
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
&url=https://www.retropassion.co.uk/product/commodore-amiga-psu-duo-a500-cd32/&media=https://i0.wp.com/www.retropassion.co.uk/wp-content/uploads/2021/08/Amiga-PSU-DUO-Amiga-A500-600-1200-and-CD32.jpg?fit=1024%2C1024&ssl=1){kind=link}
Commodore Amiga PSU for A500/600/1200 & CD32 (DUO Edition)
Commodore Amiga PSU DUO EDITION for 1 x A500/A600/A1200 and 1 x Amiga CD32 up to 8A at 5VDC strong, adjustable PSU for regular and accelerated Commodore Amiga A500, A500+, A600, A1200 and Amiga CD32.
The new Amiga PSU DUO Edition is a modern, 50W strong replacement power supply unit for Commodore Amiga computer systems.provides stable, filtered, adjustable 5VDC (up to 8.0A), 12VDC (up to 0.5A) and -12VDC (up to 0.15A) by industrial grade components. Now your Vampire, Blizzard, ACA or TF536 accelerator will get enough juice to work flawlessly with full MHz clocks. Factory trimmed for stock Amiga 500 reference load, may be adjusted to give exact 5VDC with 2-3x heavier loads.
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Key features:
- 1 x A500 A500+ A600 A1200 compatible (rectangular 5pin DIN plug)
- 1 x CD32/A590 compatible (round 4pin DIN plug)
- Stabilized, double protected +5VDC up to 8.0A rated output (total, 4A per channel max)
- Stabilized +12VDC up to 1.2A rated output (0.6A per channel max)
- Stabilized -12VDC up to 0.15A rated output
- Trim potentiometer for 5VDC fine adjustments (5-5.5V range) common for both outputs
- Double over current protection, individual for each output
- Durable main AC power On/Off switch
- Set of LED status indicators (green 5VDC, yellow 12VDC, blue -12VDC)
- Eco friendly design: consumes ~20% less power compared to original PSU set
- Configurable set of detachable output cables. Versions for regular Amiga 500/600/1200 or CD32/A590 are available (1.6 m length)
- Detachable input AC cable allowing you to use your own desired cable length (cable included)
- Weight only 0.3 KG
- Universal AC input range to support all worldwide power standards (accepts 110-240 VAC)
- Meets safety standards: UL60950-1, TUV EN60950-1, ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1
- UK Stock
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
&url=https://www.retropassion.co.uk/product/commodore-amiga-psu-for-a500-600-1200-duo-edition/&media=https://i0.wp.com/www.retropassion.co.uk/wp-content/uploads/2021/08/Amiga-PSU-DUO-Amiga-A500-600-1200-and-CD32.jpg?fit=1024%2C1024&ssl=1){kind=link}
Commodore Amiga PSU for 2 x A500/600/1200 (DUO EDITION)
Commodore Amiga PSU DUO EDITION for 2 x A500/A600/A1200, up to 8A at 5VDC strong, adjustable PSU for regular and accelerated Commodore Amiga A500, A500+, A600, A1200.
The new Amiga PSU DUO Edition is a modern, 50W strong replacement power supply unit for Commodore Amiga computer systems.provides stable, filtered, adjustable 5VDC (up to 8.0A), 12VDC (up to 0.5A) and -12VDC (up to 0.15A) by industrial grade components. Now your Vampire, Blizzard, ACA or TF536 accelerator will get enough juice to work flawlessly with full MHz clocks. Factory trimmed for stock Amiga 500 reference load, may be adjusted to give exact 5VDC with 2-3x heavier loads.
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Key features:
- 2 x A500 A500+ A600 A1200 compatible (rectangular 5pin DIN plug)
- Stabilized, double protected +5VDC up to 8.0A rated output (total, 4A per channel max)
- Stabilized +12VDC up to 1.2A rated output (0.6A per channel max)
- Stabilized -12VDC up to 0.15A rated output
- Trim potentiometer for 5VDC fine adjustments (5-5.5V range) common for both outputs
- Double over current protection, individual for each output
- Durable main AC power On/Off switch
- Set of LED status indicators (green 5VDC, yellow 12VDC, blue -12VDC)
- Eco friendly design: consumes ~20% less power compared to original PSU set
- Configurable set of detachable output cables. Versions for regular Amiga 500/600/1200 or CD32/A590 are available (1.6 m length)
- Detachable input AC cable allowing you to use your own desired cable length (cable included)
- Weight only 0.3 KG
- Universal AC input range to support all worldwide power standards (accepts 110-240 VAC)
- Meets safety standards: UL60950-1, TUV EN60950-1, ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1
- UK Stock
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Related products
Greaseweazle V4.1 USB Floppy Adapter Flux Reader Writer
Greaseweazle v4.1 allows versatile floppy drive control over USB. By extracting the raw flux transitions from a drive, any disk format can be captured and analysed - PC, Amiga, Amstrad, PDP-11, musical instruments, industrial equipment, and more. The Greaseweazle also supports writing to floppy disks, from a range of image file formats including those commonly used for online preservation (ADF, IPF, DSK, IMG, HFE)
Greaseweazle V4.1 is the latest version, updated for mass production and with the following features:
- Reads and writes 3", 3.5", 5.25", 8" disks (with suitable drive and cable)
- Buffered outputs, for communicating with older 5.25" and 8" disk drives
- Integrated power connector for directly powering most 3.5" disk drives
- Write-enable jumper can be removed for safer preservation of precious vintage disks
- Supports flippy-modded 5.25" drives
- Supports Disk-Change detection as used by Rob Smith's integration into the WinUAE Amiga emulator
- 3 user-definable outputs (eg. 8" interface REDWC signal)
- 100% factory tested, and tested again by me before shipping
More information and documentation on the wiki page here:
This listing is for the Greaseweazle V4.1 device only. And does not include which you will require:
- A disk drive (for example a PC 3.5" or 5.25" drive)
- A floppy ribbon cable (typically you want a standard PC cable with 'twist' on pins 10-16, to communicate with a PC floppy drive)
- Floppy drive power cable, or power supply
Commodore Amiga PSU for A1200
Commodore Amiga PSU for A1200, these are brand new and modern with It's 50W (55W peak) of total combined output power making it nearly 2x times stronger than original Commodore Amiga PSU and 2x smaller in dimensions & weight.
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Key features:
- Stabilized & filtered 5VDC up to 4A output (4.4A peak)
- Stabilized & filtered 12VDC up to 2A output (2.2A peak)
- Stabilized & filtered -12VDC up to 0.5A output (0.55A peak)
- Carefully calibrated for Amiga 500 reference load
- Active & passive over voltage protection for main +5VDC line
- Over current protection for all output lines
- Fully isolated & fused on AC side
- Power On/Off switch
- Long output cable (1.8m) with rectangular DIN 5-pin plug.
- Detachable input AC cable for all versions (cable included)
- Weight only 0.4 KG (2x less than original PSU)
- Runs COLD!
- Safety standards: UL60950-1, TUV EN60950-1, ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1
- Manufactured by Electroware
- UK Stock
Warning! Risk of electrical shock and energy hazard when opened. All failures should be examined by a qualified technicians only. Risk of fire or electrical shock. The ventilation holes should be protected from foreign objects or dripping liquids. Please do not install power supplies in places with high ambient temperature or close to the heat source. Enclosed power supplies are intent to work in indoor locations, it's not allowed to use power supplies outdoor, in dust or high moisture. Output current and output wattage must not exceed the rated values. This replacement Amiga PSU has been designed for Commodore Amiga 1200 vintage computer systems only and should be considered as an integral component of Amiga computer system. Do not connect to any other devices as it's not a general purpose PSU. Manufacturer is not responsible for any consequences of unauthorised or arbitrary repairs, modifications or incorrect usage. Please notice that new, properly working replacement Amiga PSU is reducing the system's potential fail rate but still is not guaranteeing that entire Amiga system will work correctly (it's >30 years old).
Sinclair ZX Spectrum 16K/48K Recapping Service
